Seeburg Acoustic Line Gsub 1501dp+

Seeburg Acoustic Line Gsub 1501dp+ The G Sub 1501 dp+ is a universal highpowered 15“ subwoofer in a low-line cabinet with an integrated 2 channel amplifier and DSP controller. Four different presets and volume settings are available to cater for a wide range of applications. The low 40 cm height makes the G Sub 1501 dp+ easy to integrate into existing stage constructions. Excellent deep bass reproduction and exclusive, modern design in an easy to handle package make the G Sub 1501 dp+ a perfect choice for demanding applications. Speaker Components 15“ Nd Description Digitally Powered Bass Extension Amp Power 1500 W AES (single Mode) / 110-230 V 2400 W AES (dual Mode) / 110-230 V 700 W AES / 4 Ω - HiMid/Sub Rated Current 5,0 A @ 230 V SPL Peak @ 1 m 135 dB Max. Input Signal 25 dBu DSP HDLM FPGA Processing 32 bit floating point AD / DA 24 bit / 96 kHz Latency 0,8 ms (analog in to analog out) Usable Range - 6 dB 35 Hz - 180 Hz Tuning Frequency excursion minimum 42 Hz Connectors Neutrik XLR in/out Neutrik PowerCon in/out 2 x Neutrik Speakon NL4MP out Handles 2 x Rigging / Fittings M20 on top Wheelboard fittings Weight 29,5 kg (+ 6,0 kg wheelboard) Size height x width x depth 40,0 x 60,0 x 60,0 cm
